UCIe Consortium releases Spec 2.0 supporting MSA and 3D packaging

Advances an open chiplet ecosystem by releasing the latest specification supporting 3D packaging, manageability system architecture, and more

author-image
DQI Bureau
New Update
chipletlog
Listen to this article
0.75x 1x 1.5x
00:00 / 00:00

The Universal Chiplet Interconnect Express (UCIe) Consortium announced the release of its 2.0 Specification.

Advertisment

UCIe 2.0 Specification adds support for a standardized system architecture for manageability and holistically addresses the design challenges for testability, manageability, and debug (DFx) for the SIP lifecycle across multiple chiplets – from sort to management in the field.

The introduction of optional manageability features and a UCIe DFx Architecture (UDA), which includes a management fabric within each chiplet for testing, telemetry, and debug functions, allows vendor agnostic chiplet interoperability across a flexible and a unified approach to SIP management and DFx operations.

Additionally, the 2.0 Specification supports 3D packaging – offering higher bandwidth density and improved power efficiency compared to 2D and 2.5D architectures. UCIe-3D is optimized for hybrid bonding with a bump pitch functional for bump pitches as big as 10-25 microns to as small as 1 micron or less to provide flexibility and scalability.

Advertisment

Another feature is optimized package designs for interoperability and compliance testing. The goal of compliance testing is to validate the main-band supported features of a Device Under Test (DUT) against a known- good reference UCIe implementation. UCIe 2.0 establishes an initial framework for physical, adapter, and protocol compliance testing.

Highlights of the UCIe 2.0 specification:
• Holistic support for manageability, debug, and testing for any System-in-Package (SiP)
construction with multiple chiplets.
• Support for 3D packaging to significantly enhance bandwidth density and power efficiency.
• Improved system-level solutions with manageability defined as part of the chiplet stack.
• Optimized package designs for interoperability and compliance testing.
• Fully backward compatible with UCIe 1.1 and UCIe 1.0.

Brian Rea, Marketing WorkGroup Chair,UCIe, will be presenting on: Enabling an Open Chiplet Ecosystem at the Package Level, UCIe at the Chiplet Summit, Jan. 21-23, USA.
