Engineering semiconductor chips that think and learn!

The semiconductor industry faces a defining moment. Engineering teams around the world are realizing that traditional chip design methodologies, which have been reliable for decades, are now reaching their limits. These methods struggle just as the demand grows for chips capable of thinking, learning, and adapting in real time.

This creates a dual challenge where organizations must harness AI to transform chip design and manufacturing while simultaneously engineering specialized processors optimized for AI workloads.

The market opportunity is enormous. The global AI chip market grew to $166.9 billion in 2025, and is predicted to reach $311.58 billion by 2029, representing a CAGR of 24.4%. Capturing this growth requires more than incremental improvements. Companies face a fundamental transition from conventional von Neumann processors to neuromorphic designs and domain-specific accelerators while reimagining fabrication through AI-driven optimization.

Organizations that successfully bridge AI and semiconductor engineering and integrate the domain-specific expertise of multiple industries needing custom silicon will be well positioned to lead this transformation. The technical hurdles span advanced node design challenges, specialized AI-centric architectures, intelligent manufacturing systems, and entirely new testing paradigms. Yet the rewards for those who navigate this convergence successfully will define market leadership for the next decade.

Quest Global stands ready to guide this evolution, leveraging our unique silicon-to-systems-to-cloud capability to deliver end-to-end solutions. This white paper explores how AI is revolutionizing VLSI design and production, how VLSI technologies enable the AI revolution, and how Quest Global’s expertise positions clients to thrive in this transformed landscape.

Convergence of AI and VLSI driving a dual shift
Semiconductor engineers today face an unprecedented challenge. At the 2nm node, for example, where transistor features measure mere billionths of a meter, designers face intense challenges related to device physics, variability, and power density. These same teams must also architect chips capable of real-time learning and adaptation, such as AI accelerators for autonomous systems.

This creates a fundamental tension where Moore's Law continues driving the push for smaller, faster transistors, while AI workloads demand entirely different architectures. The goal has shifted from packing more transistors or boosting the clock speed to creating systems that process unstructured sensor data, respond to dynamic environments, and operate within power and thermal constraints that would have challenged earlier generations of designers.

Consider autonomous vehicle perception systems, which must fuse data from cameras, LiDAR, radar, and sensors in real time under strict safety requirements. These systems demand chips capable of massive parallel processing with minimal latency, while consuming low power and remaining reliable for decades. Traditional CPU architectures, built for sequential instruction execution, struggle with this level of parallelism and power efficiency.

This design complexity is where AI transforms how we approach chip development. Machine learning algorithms now optimize complex design parameters that would take human engineer’s months to explore manually. Genetic algorithms evaluate thousands of design parameter combinations, selecting and refining the best performers over successive runs.

AI-driven placement and routing tools reduce design cycles from weeks to days, while achieving better power and performance results. These tools handle the time-consuming parameter iterations, giving designers more bandwidth for architectural innovation. The exponentially growing design space makes AI essential for semiconductor development, from mature nodes to the most advanced processes.

AI-driven design methodologies are reshaping chip development
AI is transforming chip design by introducing EDA tools that learn, adapt, and optimize beyond traditional rule-based approaches. These AI systems operate across multiple layers, from high-level architectural decisions down to transistor-level optimizations, enabling design toolchains to improve using data and patterns from past projects.

Companies like STMicroelectronics report 3× productivity improvements and 25% lower power consumption using platforms like Synopsys's DSO.ai, which has supported over 100 chip tape-outs. AI tools automate tedious optimization work, freeing engineers for creative problem-solving when experienced designers are increasingly scarce.

Applying AI in semiconductor manufacturing for yield and quality gains
AI is revolutionizing semiconductor fabrication, giving rise to the "smart fab" concept. Modern semiconductor fabrication plants involve hundreds of process steps with equally many opportunities for problems. Even small improvements in yield can translate into tens of millions of dollars saved at scale. AI is now deployed at multiple levels in manufacturing.

Specialized VLSI architectures built to support AI workloads
Just as AI changes how we make chips, it also changes what chips we make. Traditional general-purpose processors are ill-suited for many AI tasks, especially deep learning, due to their limited parallelism and memory bandwidth. This has driven a pivot toward specialized computing architectures purpose-built for AI workloads. The promise lies in significant efficiency gains in times to come.

Neuromorphic systems can be up to 1000× more energy-efficient than conventional CPUs or GPUs on AI workloads. IBM's TrueNorth contains 1 million neurons and 256 million synapses yet operates on merely 70 milliwatts. Intel's Loihi 2 can perform some computations with 1000× less energy than typical AI chips.

Accelerators for deep learning and transformers
The workhorse of today's AI revolution remains deep learning based on large neural networks, including transformer models powering natural language processing. These computationally intensive workloads have spawned various domain-specific accelerators, from GPUs repurposed for parallel tensor math to custom ASICs like Google's TPU.

Advanced memory, packaging, and integration for AI systems
Innovation extends beyond chips to how they are packaged and integrated into systems. Advanced packaging has become critical for AI hardware design. The fastest computing die can be bottlenecked, if it cannot efficiently communicate with memory or other chips.

Designing for safety and reliability in AI chips
In automotive, aerospace, and healthcare domains, AI chips must be safe and reliable under all conditions. When an AI accelerator is part of an autonomous driving system or a flight control computer, failures can be life-threatening. There is a strong push to engineer AI hardware with built-in safety mechanisms meeting standards like ISO 26262 at the ASIL-D level.

Quest Global has significant experience in designing functional safety architectures. We have contributed to projects where AI-enabled vision processors had to meet ASIL-D compliance, implementing dual-core lockstep configuration and developing safety manuals for ISO 26262 certification.

Rethinking test and validation for AI chips
Designing an AI chip is only half the battle; verifying that it works correctly under all scenarios is equally challenging. AI-enabled silicon blurs the line between hardware and software, running probabilistic algorithms, learning from data over time, and exhibiting behaviour that shifts based on complex inputs. Traditional chip verification techniques must be enhanced for an AI-driven adaptive environment, yielding better coverage and efficiency.

Imperative of strategic partnerships and cross-domain integration
The complexity of modern AI chip development has fundamentally altered how semiconductor companies innovate and deliver products. No single organization can realistically maintain all the expertise needed, from AI algorithms to deep sub-micron silicon design and manufacturing know-how. Strategic engineering partnerships and collaborative ecosystems are now imperative for custom silicon for specific verticals, like auto, aero, oil and gas, transport, bio-medicals, etc.

Quest Global’s Silicon-to-Systems-to-Cloud ecosystem
Quest Global positions itself as a key partner in this collaborative model through integrated engineering services spanning the entire spectrum of AI chip development, the "Silicon to Systems to Cloud" journey. On the silicon side, we provide turnkey ASIC/SoC design from capturing specifications to delivering a completely working system.

Moving upward, we cover system-level integration, including embedded software, firmware, and board design. Extending to the cloud, our expertise includes cloud integration and IoT, understanding how data and insights from devices get aggregated securely and efficiently.

Success stories on AI-led semiconductor innovation
Automotive AI hardware platform: For a top-tier automotive supplier, Quest Global co-developed an ADAS and AD (autonomous driving) hardware platform. Leveraging AI-driven design optimizations and a sophisticated SoC architecture tailor-made for sensor fusion achieved a 40% reduction in development time for the vehicle's ECU.

AI-enhanced design methodology: In a complex 7nm SoC project for a consumer electronics client, Quest Global implemented an AI-enhanced RTL design flow. Introducing machine learning into RTL verification, and using reinforcement learning to guide place-and-route delivered 30% faster design convergence, shaving weeks off the schedule.

Verification and first-pass success: For a networking chip company incorporating AI accelerators, Quest Global provided verification services. Through advanced formal property checking and large-scale FPGA prototyping, we reduced verification cycles by 25% and delivered a first-pass silicon.

High-performance AI chipset: Quest Global assisted in developing a first-of-its-kind AI-HPC chipset. We helped integrate 150 functional IP blocks, and our low-power design strategies yielded a significant improvement in power efficiency at the chip level.

Yield and test optimization: A major semiconductor manufacturer was struggling with inconsistent yields on their 16 nm production line. Quest Global analysed its factory data using machine learning to identify hidden patterns affecting chip quality. The insights led to process adjustments that improved yield by 15% across subsequent production runs.

Opportunities and challenges
The convergence of AI and VLSI presents immense opportunities, alongside notable challenges.

Opportunities in using AI for VLSI: Reduced time-to-market through AI-augmented design automation can drastically shorten design cycles, enabling faster market entry. Improved design quality emerges from machine learning, exploring designs beyond human intuition.

Smart manufacturing efficiency offers the potential for "zero-defect" manufacturing with real-time control. End-to-end optimization envisions closed-loop systems where data from manufacturing and field operations feeds back to influence the next design iteration.

Challenges in using AI for VLSI: Data and model availability require investment in data infrastructure and teams of data scientists. Integration into workflows requires change management and building engineer trust in AI suggestions. Verification and accountability raise questions about responsibility when AI designs part of the chip.

Opportunities in designing chips for AI: Rapidly growing market demand creates abundant opportunities for new entrants and existing players to carve out niches. Diverse application avenues span healthcare, automotive, finance, and defence. Architectural innovation opens up opportunities to move beyond legacy architectures.

Challenges in designing chips for AI: Intense competition in a crowded, fast-moving arena has risk of obsolescence as algorithm paradigms shift. Power and thermal constraints require balancing performance with deployability in real environments. Software and ecosystem development demands building compiler, library, and framework support. Reliability and ethical considerations require security features and unbiased operation.

Engineering the intelligent future
The integration of AI into semiconductor technology marks a profound shift in how we approach our craft. Building "chips that think and learn" would have seemed impossible just a few years ago, yet here we are, facing both extraordinary possibilities and formidable engineering challenges. The traditional measures of success no longer tell the complete story.

Clock speeds and transistor count matter less when creating systems that need to perceive, learn, and adapt. This requires us to rethink everything from design methodologies to manufacturing processes, from verification approaches to reliability standards.

Organizations that acknowledge this reality and invest thoughtfully in AI-driven design, specialized architectures, and cross-domain expertise are building the foundation for long-term success. The companies thriving in this environment understand that partnership and collaboration are essential.

At Quest Global, we see ourselves as engineering partners committed to helping our clients navigate this transformation successfully. Our Silicon-to-Systems-to-Cloud approach reflects the integrated thinking this new era demands.

The convergence of AI and semiconductor technology has created a powerful cycle where smarter chips enable better AI, and better AI leads to even more intelligent silicon. These innovations represent more than technological progress. They will define the decade ahead. Together, we are building the chips and engineering the intelligent systems that will shape our world.

-- Sudipto Das, AVP, Semiconductor Vertical at Quest Global, and Avi Seegehalli, AVP, Semiconductor Vertical at Quest Global.
